BLACKCOMB HO 6.1 A

NSF validated UV water filtration system

Looking for the ultimate in higher flow rates, then LUMINOR's NSF Class A BLACKCOMB-HO 6.1 line of "Residential Crossover" UV treatment systems should be your choice. Installed in a large residence or in a light commercial application, continuous UV monitoring is provided by the inclusion of a true 254nm discrete UV monitor. Using Teflon technology for reduced fouling, these sensors allow for the addition of a solenoid shut-off valve and a 4-20mA output allowing for remote monitoring or data logging. A colour user interface allows for easy visual identification of UV intensity, remaining lamp life and any error or fault codes as well as a monitoring of a full system diagnostic on start-up. The UV system even incorporates QR codes to access lamp change information and videos via web access. The controller's universal input, constant current electronic power source is housed in a splash-proof case and comes standard with a "future-proof" expandability port for future upgrades or options. Commercial grade, axial flow 316L stainless steel, single-end reactors allow for lamp change without the need to drain the reactor chamber. Reliable, industry proven, high quality low pressure, high-output (LP-HO) coated UV lamps offer a consistent output over their 10,000 hour life. Flow rates of 15, 21, 30, & 49 lpm (4, 5.5, 8, & 13 gpm), in both 120V or 230V applications (same ballast, different IEC power cord), are offered in the NSF Class A BLACKCOMB-HO 6.1 series of products. For more information on NSF please visit their site at www.nsf.org.

Optional Equipment Modules

Solenoid Module (MOD-SOL1)

Solenoid Module (MOD-SOL1)

  • Allows for a solenoid connection on LUMINOR BLACKCOMB (5.1 and 6.1 only) products (will work on lamp failure only on LUMINOR 5.1 systems)
  • Customer simply needs to purchase a NORMALLY CLOSED line voltage solenoid valve and affix the module’s supplied bare lead cord to the solenoid valve
  • Connect power cable to electrical outlet and the other lead to the “future-proof” expandability port on the controller

4-20 mA Module (MOD-420)

4-20 mA Module (MOD-420)

  • Allows for a 4-20mA connection on LUMINOR BLACKCOMB (5.1 and 6.1 only) products
  • This device will allow for a 4-20mA signal transfer of the UV output to a remote device such as a data logger or computer
  • Simply plug the supplied into the IEP expandability port on the UV sensor module (or daisy chain to any other module used in the system
  • No wire is supplied with this system, however 16-22 AWG is required

Remote Alarm (Dry Contacts) Module (MOD-RAM-C)

Remote Alarm (Dry Contacts) Module (MOD-RAM-C)

  • Allows for a remote connection on LUMINOR BLACKCOMB (5.1 and 6.1 only) products
  • Allows for the remote installation of alarms, lights, PLC input, data logger, flow control, etc.
  • Simply plug the supplied into the IEP expandability port on the UV sensor module (or daisy chain to any other module used in the system
  • Supplied with three screw terminals (NO, NC & common) to connect to the receiving end of the dry contacts
  • As the distance required is unknown, no wire is supplied with the system, however 16-22 AWG is required

SHERPA

SHERPA

  • Wireless remote monitoring within the home….works on  all LUMINOR (both 5.1 and 6.1) products
  • Integral audible alarm and visual indicators for “GOOD”, “CAUTION”, and “ALARM” conditions
  • Hard wire option only (wall wart) (battery option to follow)
  • Supplied with both the receiver and transmitter which is connected to the IEP port of the controller as are other modules
  • Flexible mounting configurations
  • Can install up to 5 receivers per transmitter

Dealer Programming Module

Dealer Programming Module

As a dealer or distributor of UV systems, you realize the importance of making sure that your customers replace their UV lamps on a regular basis. Other systems come with lamp change reminders, but they do not ensure the repeat business comes back to you!

LUMINOR's BLACKCOMB line of UV systems come with the industry's first Dealer Programming Module. This module allows you to customize the controller's display in the field!
