BLACKCOMB-HO 6.1

High Output UV water treatment system

For higher flow rates, consider LUMINOR's BLACKCOMB-HO 6.1 line of "Residential Crossover" UV water treatment systems.



Installed in a large residence or in a light commercial application, continuous UV water quality monitoring is provided by the inclusion of a true 254nm discrete UV monitor. Using Teflon technology for reduced fouling, these sensors allow for the addition of a solenoid shut-off valve and a 4-20mA output allowing for remote monitoring or data logging.



A colour user interface allows for easy visual identification of UV intensity, remaining lamp life and any error or fault codes as well as a monitoring of a full system diagnostic on start-up. The system also incorporates QR codes to access lamp change information and videos via web access. The controller's universal input, constant current electronic power source is housed in a splash-proof case and comes standard with a "future-proof" expandability port for future upgrades or options.



Commercial grade axial flow 316L stainless steel, single-end reactors allow for lamp change without the need to drain the reactor chamber. Low pressure, high-output (LP-HO) coated UV lamps offer a consistent output over their 10,000 hour rated life and come paired with LUMINOR's encrypted lamp key technology to protect against improper use.



Flow rates of 15, 38, 53, 95 & 150 lpm (5, 10, 15, 25 & 40 gpm), in both 120V or 230V applications (same UV ballast, different IEC power cord), are offered in the BLACKCOMB-HO 6.1 series of products. Also available in NSF Class B or NSF Class A.



BLACKCOMB UV System

Note: BLACKCOMB 5.1 High Output (non-NSF) system shown.

Optional Equipment Modules

Solenoid Module (MOD-SOL1)

Solenoid Module (MOD-SOL1)

  • Allows for a solenoid connection on LUMINOR BLACKCOMB (5.1 and 6.1 only) products (will work on lamp failure only on LUMINOR 5.1 systems)
  • Customer simply needs to purchase a NORMALLY CLOSED line voltage solenoid valve and affix the module’s supplied bare lead cord to the solenoid valve
  • Connect power cable to electrical outlet and the other lead to the “future-proof” expandability port on the controller

4-20 mA Module (MOD-420)

4-20 mA Module (MOD-420)

  • Allows for a 4-20mA connection on LUMINOR BLACKCOMB (5.1 and 6.1 only) products
  • This device will allow for a 4-20mA signal transfer of the UV output to a remote device such as a data logger or computer
  • Simply plug the supplied into the IEP expandability port on the UV sensor module (or daisy chain to any other module used in the system
  • No wire is supplied with this system, however 16-22 AWG is required

Remote Alarm (Dry Contacts) Module (MOD-RAM)

Remote Alarm (Dry Contacts) Module (MOD-RAM)

  • Allows for a remote connection on LUMINOR BLACKCOMB (5.1 and 6.1 only) products
  • Allows for the remote installation of alarms, lights, PLC input, data logger, flow control, etc.
  • Simply plug the supplied into the IEP expandability port on the UV sensor module (or daisy chain to any other module used in the system
  • Supplied with three screw terminals (NO, NC & common) to connect to the receiving end of the dry contacts
  • As the distance required is unknown, no wire is supplied with the system, however 16-22 AWG is required

SHERPA

SHERPA

  • Wireless remote monitoring within the home….works on  all LUMINOR (both 5.1 and 6.1) products
  • Integral audible alarm and visual indicators for “GOOD”, “CAUTION”, and “ALARM” conditions
  • Hard wire option only (wall wart) (battery option to follow)
  • Supplied with both the receiver and transmitter which is connected to the IEP port of the controller as are other modules
  • Flexible mounting configurations
  • Can install up to 5 receivers per transmitter

Module Splitter

Module Splitter

This module helps organize all the modules connected to BLACKCOMB 5.1/6.1 systems. Up to 3 modules, including sensors, can plug into the MOD-SPLITTER at once. Managing modules becomes easier as they are all plugged into one, central location.

UV Concierge Module (MOD-APP)

UV Concierge Module (MOD-APP)

• Integrated WiFi solution for WEB, ANDROID, and iOS (Apple)
• GUI interface matches current UV display for brand recognition
• Easy set-up and login with integrated QR codes
• Data logging capabilities (i.e. UV output over time)
• Safe & protected, cloud-based data management
• Monitor just one system, or ALL the systems that you may service
• FCC compliance

Ultrasonic Flow Meter Module

Ultrasonic Flow Meter Module

LUMINOR’s ULTRASONIC FLOW METER provides accurate, real-time flow monitoring using a technology that provides failsafe operation. When the system senses “no-flow” or "low-flow" conditions, a signal is sent to the main controller and automatically reduces the power output to the UV lamp, thereby reducing the overall power consumption. Benefits include energy savings, reduced quartz sleeve fouling and cooler operating temperatures.

Dealer Programming Module

Dealer Programming Module

As a dealer or distributor of UV systems, you realize the importance of making sure that your customers replace their UV lamps on a regular basis. Other systems come with lamp change reminders, but they do not ensure the repeat business comes back to you!

LUMINOR's BLACKCOMB line of UV systems come with the industry's first Dealer Programming Module. This module allows you to customize the controller's display in the field!
